SECHE
S – SQ SECHE :
Versatile et fiable, avec le tambour en acier inox, ces séchoirs peuvent être électriques, à vapeur, ou à gaz ; le computer est une option très économique qui permet une flexibilité jamais pensée pour des séchoirs ainsi que la possibilité de traiter tout type de vêtements en toute tranquillité.
Disponibles aussi les modèles à circuits fermés : Quand la ventilation vers l’extérieur se révèle être un problème
MODEL | UM | S 10 | S 16 | S 25 | S 35 | S 55 | S 120 |
---|---|---|---|---|---|---|---|
Capacity | kg lb | 10 22 | 16 35 | 25 55 | 36 80 | 55 121 | 120 265 |
Diameter | mm | 695 | 763 | 900 | 1000 | 1125 | 1463 |
Volume | dm3 | 216 | 334 | 492 | 726 | 1100 | 2448 |
Drum motor | kw | 0.37 | 0.37 | 0.37 | 0.55 | 1.1 | 2 |
Fan motor | kw | 0.25 | 0.25 | 0.25 | 0.35 | 1.1 | 2.5 |
Air exhaust | mm | 195 | 195 | 195 | 195 | 300 | 250 X 2 |
Consumptions | |||||||
Gas | cal/h | 15000 | 20000 | 25000 | 25000 | 50000 | 240000 |
Electricity | kw | 12 | 18 | 18 | 25 | 6538.6 | 38.6 |
Steam | kg/h | 22 | 35 | 50 | 65 | 125 | 300 |
Dimensions | |||||||
Length | mm | 740 | 810 | 950 | 1055 | 1250 | 1850 |
Depth | mm | 950 | 1120 | 1150 | 1215 | 1600 | 2350 |
Height | mm | 1505 | 1690 | 1830 | 1935 | 2150 | 2080 |
Weight | kg lb | 160 353 | 220 485 | 260 573 | 350 772 | 660 1455 | 2080 4586 |
TUMBLE DRYERS SQ CLOSED CIRCUIT
Innovative tumble dryers with closed circuit recovery of drying flow
The SQ dryers are innovative closed circuit dryers in which the air used it is not discharged outside but is recovered thanks to a refrigeration unit working with Freon R407C.
It is no longer necessary to have a duct for external evacuation of the drying process vapors and fumes. Moreover, the reduction of energy consumption is extremely high.
ITALCLEAN SQ dryers are the best solution if there is no possibility for evacuating the air outside of the premises because of high cost, need for permission or construction problems.
MODEL | UM | SQ 16 | SQ 25 |
---|---|---|---|
Capacity | kg lb | 16 35 | 25 55 |
Diameter | mm | 763 | 900 |
Volume | dm3 | 334 | 492 |
Drum motor | kw | 0.37 | 0.37 |
Fan motor | kw | 0.55 | 0.55 |
Consumptions | |||
Electricity | kw | 10.5 | 10.5 |
Steam | kg / h | 12 | 15 |
Dimensions | |||
Length | mm | 810 | 950 |
Depth | mm | 1370 | 1400 |
Height | mm | 2080 | 1900 |
Weight | kg lb | 300 661 | 340 750 |
